Military Aviation Connector Y11P-1419ZJ10 |

High-Density Micro-D Connector for Critical Avionics

Product Overview

The YM Military Aviation Connector Y11P-1419ZJ10 is a premium, high-density Micro-D subminiature connector system engineered for mission-critical signal transmission in space-constrained aerospace and defense applications. Designed specifically for integration with Military Aviation Band Switch systems, Aviation Temperature Sensor networks, and drone flight control units, this connector provides reliable performance where traditional connectors are too large. As part of YM's comprehensive aviation component portfolio—which includes complementary products like Military Aviation Encoding switch and Aviation Hours Timer—the Y11P-1419ZJ10 delivers exceptional signal integrity and environmental protection in the most demanding miniaturized applications.

Core Advantage: Maximum contact density in a Micro-D form factor with military-grade environmental sealing, providing reliable interconnection where space is severely limited but performance cannot be compromised.

Product Image

Detailed image showing the compact design and precision construction of the Micro-D connector system.

Technical Specifications

Model: Y11P-1419ZJ10
Connector Type: High-Density Micro-D Subminiature
Shell Characteristics:
- Shell Size: Ultra-compact Micro-D footprint
- Material: Steel with corrosion-resistant electroplating
- Mounting: Surface mount (SMT) or through-hole configurations
Contact System:
- Contact Pitch: 0.050" (1.27mm) or 0.025" (0.635mm) high-density options
- Contact Types: Machined contacts with selective gold plating over nickel barrier
- Current Rating: 1A per contact (signal applications)
- Contact Density: Up to 104 positions in minimal space
- Contact Resistance: ≤25mΩ maximum initial resistance
Electrical Performance:
- Voltage Rating: 250V AC/DC working voltage
- Insulation Resistance: >5000 MΩ at 500V DC
- Dielectric Strength: 1000V AC RMS between contacts
- EMI/RFI Shielding: >60dB effectiveness (30MHz-1GHz)
Environmental Specifications:
- Ingress Protection: IP67 rated when properly mated
- Operating Temperature: -55°C to +125°C
- Sealing Technology: Advanced compression micro-seals
- Vibration Resistance: Meets MIL-STD-1344 requirements
- Coupling Mechanism: Screw-lock system for secure mating

Product Features & Advantages

Maximum Contact Density: Provides the highest available pin count in the Micro-D form factor, enabling complex avionics systems to interface multiple components like Aviation Rocker Switch controls and Aviation Pressure Sensor inputs in minimal space.
Advanced Micro-Environmental Sealing: Precision-engineered sealing system provides complete environmental protection comparable to our Military Aviation Socket products, ensuring reliability in harsh aviation environments.
Superior Signal Integrity: Optimized contact geometry and shielding design maintain signal integrity for critical applications interfacing with Aviation Hours Timer and Military Aviation Encoding switch systems.
Military-Grade Durability: Meets rigorous MIL-DTL-83513 specifications for vibration, shock, and mechanical stress, ensuring compatibility with other military-grade components like Military Electronic Horn and Aviation Magnetic Valve systems.
High-Temperature Compatibility: Materials and construction withstand extreme temperatures from -55°C to +125°C, suitable for integration with Aviation Temperature Sensor networks and engine control systems.
EMI/RFI Protection: Advanced shielding design provides superior electromagnetic compatibility when connecting to sensitive Aviation Press Meter displays and communication equipment.

Our Manufacturing Advantage: YM leverages decades of precision manufacturing experience from producing Military Aviation connector systems and Aviation Microswitch components to create Micro-D connectors with exceptional dimensional accuracy and reliability.

How to Integrate the Y11P-1419ZJ10 Connector

System Requirements Analysis: Determine signal count and space constraints. Micro-D connectors are ideal when interfacing multiple Aviation Button Switch controls or sensor arrays in compact spaces.
Configuration Selection: Select appropriate pin count (15-104 positions) and mounting style based on PCB design. Consider compatibility with existing Military aircraft Plug systems.
PCB Design Preparation: Design PCB with proper pad patterns and thermal management for Micro-D connector installation, similar to requirements for PCB Board Relay integration.
Precision Assembly Process: Use controlled reflow soldering for surface mount versions. Ensure proper alignment and thermal management during assembly.
System Integration and Testing: Connect to complementary systems like Aviation Swing arm Switch controls or Aviation Oxygen Valve monitors. Perform comprehensive electrical and environmental testing.

Application Scenarios

The Y11P-1419ZJ10 is essential for advanced miniaturization across aviation and defense systems:

Drone Flight Control Systems: Interfaces micro flight controllers with Aviation Temperature Sensor arrays, Aviation Pressure Release Valve controls, and navigation systems in compact UAV designs.
Aircraft Instrumentation Panels: Connects Military Aviation Band Switch controls, Aviation Ammeter displays, and cockpit warning systems in space-constrained instrument clusters.
Engine Control Units: Interfaces between engine sensors and control systems, working alongside Aviation Cold Air Solenoid Valve and Hydraulic Circuit Breaker components.
Military Communication Systems: Provides high-density connections in portable military radios and electronic warfare equipment, complementing Military Electronic Horn systems.
Sensor Network Integration: Connects multiple Military Pressure Sensor and Aviation Haulage Pressure Sensor units to central monitoring systems in aircraft and ground support equipment.
Ground Support Equipment: Used in portable test equipment interfacing with Aviation Copper Fuse Holder systems and Aviation Single Hydraulic Valve controls.

Value for Buyers: Enables significant size and weight reduction in aviation systems, allows higher integration density for advanced functionality, maintains reliability in extreme environments, reduces installation complexity through consolidated connections, and provides long-term durability matching other military-grade components.

Certifications & Compliance

Manufactured in our SGS-audited facility, the Y11P-1419ZJ10 meets MIL-DTL-83513 specifications for Micro-D connectors and is produced under ISO 9001:2015 certified quality management systems. Our connectors comply with RoHS and REACH directives, and we support project-specific certifications including UL, CE, and military qualification testing. This certification approach aligns with our production of other aviation components like Aviation Oil Sealed Valve and Aviation Magnetic Valve systems.

Customization Options

YM provides extensive customization for the Y11P-1419ZJ10 to meet specific application requirements:

Custom Pin Configurations: Design specialized contact arrangements for specific Aviation Rocker Switch or sensor interface requirements.
Special Mounting Designs: Custom surface mount configurations or right-angle designs for unique installation scenarios in aircraft systems.
Enhanced Environmental Sealing: Special sealing solutions for integration with Aviation Oxygen Valve systems or other critical Aviation Applications.
High-Speed Data Versions: Optimized designs for interfacing with advanced Military Aviation Encoding switch systems requiring high data rates.
Complete Cable Assemblies: Pre-terminated cable systems for plug-and-play installation with Military Aviation socket and other connector systems.
Special Identification Marking: Custom laser marking for part numbering and system identification in complex aviation installations.

Our extensive OEM/ODM experience with aviation components, including Aviation Microswitch and Aviation Button Switch systems, enables us to provide tailored connector solutions for your specific aviation requirements.

Production & Quality Assurance

Every Y11P-1419ZJ10 connector undergoes rigorous manufacturing and testing processes:

Precision Micro-Stamping: Contacts are produced using advanced micro-stamping technology maintaining tight tolerances required for aviation applications.
Selective Gold Plating: Precision plating processes apply gold to critical contact areas, similar to techniques used for Military Aviation connector contacts.
High-Precision Molding: Insulators are injection molded with exacting dimensional control for reliable performance in vibration-intensive environments.
Automated Assembly: Robotic assembly systems ensure consistent quality and proper alignment of miniature components.
Comprehensive Inspection: 100% automated optical inspection verifies critical dimensions and assembly quality.
Rigorous Testing: Electrical testing includes continuity, insulation resistance, and dielectric strength verification, plus environmental testing matching standards for Aviation Temperature Sensor components.

This quality assurance program ensures connectors meet the same high standards as our other aviation components, including Aviation Hours Timer and Military Pressure Sensor products, for reliable performance in critical applications.
