Military Aviation Connector Y11P-2255ZJ10 |

High-Density Rectangular Connector for Complex Systems

Product Overview

The YM Military Aviation Connector Y11P-2255ZJ10 is a high-performance, multi-pin rectangular connector engineered for sophisticated electrical systems in aerospace, unmanned vehicles, and advanced transportation applications. Designed to accommodate a high density of signal and power contacts within a rugged, compact housing, this connector is ideal for interfacing complex avionics, engine control units, and train control systems. As a critical component in systems that also utilize precision control devices like PCB Signal Relays and Solid State Relays, the Y11P-2255ZJ10 provides a reliable, sealed interface that maintains signal integrity and power continuity in the most demanding environments. Its rectangular form factor offers optimal space utilization in modern, densely packed electronic enclosures.

Core Advantage: Exceptional contact density combined with military-grade environmental sealing and a robust locking mechanism, delivering reliable performance in space-constrained, high-vibration applications.

Product Image

Technical illustration showcasing the connector's rectangular profile, mounting features, and dimensional specifications for integration planning.

Technical Specifications

Model: Y11P-2255ZJ10
Connector Type: High-Density Rectangular, Metal Shell
Shell Material: Aluminum Alloy with Conductive, Corrosion-Resistant Finish
Contact System:
- Contact Configuration: High pin count arrangement (specific count defined by model suffix).
- Contact Type: Removable crimp or solder contacts, typically gold-plated for low contact resistance and durability.
- Current Rating: Mixed capacity contacts supporting signal levels (≤3A) and power circuits (up to 10A or more per contact).
- Contact Resistance: Typically ≤10mΩ per contact to ensure efficient power transfer and signal fidelity.
Electrical Performance:
- Voltage Rating: Rated for operation up to 250V AC/DC or higher, suitable for standard aviation 28V DC systems and compatible with circuits protected by Industrial Power Relays.
- Insulation Resistance: >5000 MΩ at 500V DC minimum.
- Dielectric Strength: Withstands 1500V AC RMS between contacts and between contacts and shell.
Mechanical & Environmental:
- Coupling Mechanism: Robust screw-lock or cam-lock system for secure mating and high vibration/shock resistance.
- Ingress Protection: Standard IP65 (dust-tight and protected against water jets). IP67 sealing available with proper gasket installation.
- Operating Temperature: -55°C to +125°C standard range.
- Sealing: Silicone or fluorosilicone gaskets provide environmental sealing at the interface and cable entry.
- Mounting: Designed for secure panel mounting via integrated flanges with mounting holes.

Product Features & Advantages

Optimized High-Density Design: The rectangular layout maximizes the number of contacts per unit area, allowing consolidation of multiple discrete wire connections into a single, manageable interface—ideal for modern PCB Board Relay control panels.
Superior Mechanical Locking: The screw or cam-lock mechanism ensures a secure, vibration-proof connection that will not back out, critical in aerospace and railway applications subject to constant motion.
Excellent EMI/RFI Shielding: The full-metal shell and optional shielded backshells provide outstanding protection against electromagnetic interference, safeguarding sensitive signals to and from components like Solid State Relays and communication modules.
Removable Contact Design: Contacts can be individually inserted and removed, allowing for easy field repair, contact replacement, and wiring configuration changes without replacing the entire connector.
Rugged Environmental Sealing: High-performance gaskets and sealing glands protect the connection from moisture, dust, and fluids, offering reliability comparable to that of a Metal Sealing Relay in harsh conditions.
Polarized and Keyed Design: Incorporates foolproof polarization features to prevent mismating, ensuring correct connection of complex harnesses every time.

Our Manufacturing Advantage: YM applies its extensive expertise in precision metal fabrication and electrical contact technology—honed through manufacturing Polarized Relays and Military Metal Relays—to produce the Y11P-2255ZJ10. This ensures exceptional shell machining accuracy, consistent contact plating quality, and reliable sealing surface finishes.

How to Specify and Install the Y11P-2255ZJ10 Connector

System Interface Definition: Map out all signals and power lines requiring connection. Determine the total pin count and segregate by current level (signal vs. power).
Connector Configuration: Select the appropriate Y11P-2255ZJ10 variant with the required number and type of contacts. Choose the correct backshell and sealing gland for your cable diameter.
Contact Termination: Using calibrated tooling, crimp or solder wires to the removable contacts according to the pin-out diagram. Ensure each contact is fully seated in the connector insert.
Harness Assembly: Route the cable through the backshell and sealing gland. Assemble the insert into the shell housing, install all seals, and tighten the backshell to achieve the proper environmental seal.
Panel Mounting & Final Mating: Mount the connector receptacle to the panel. Align the plug and receptacle using the polarization key, then engage and tighten the locking mechanism (screws or cam) to the specified torque. Perform electrical verification tests.

Application Scenarios

The Y11P-2255ZJ10 is the connector of choice for complex, multi-line interconnections in demanding fields:

Aircraft Avionics Bays: Primary interface for flight control computers, integrating dozens of sensor inputs, control outputs, and communication lines.
Unmanned Aerial System (UAS) Central Hubs: Connects the main flight controller to peripheral modules like GPS, telemetry, gimbals, and payload controllers in compact drone airframes.
Railway Vehicle Control Cabinets: Used as a main interface connector in traction control units or passenger information system hubs, where many control signals from Automotive Relays and sensors converge.
Military Vehicle Electronics: Interconnects between crew stations, weapon control systems, and vehicle management computers in armored platforms.
Industrial Automation Racks: Provides a robust interface for programmable logic controller (PLC) I/O modules, especially in environments requiring sealed connections.
New Energy Vehicle Powertrain: Can be specified for high-density connections within battery management systems or power distribution units, working alongside New Energy Relays.

Value for Buyers: Reduces wiring complexity and installation time, improves system reliability by minimizing multiple point-to-point connections, enhances serviceability with removable contacts, provides superior protection for sensitive electronics, and offers a professional, robust interface for high-value equipment.

Certifications & Compliance

Manufactured in our SGS-audited facility under a certified quality management system, the Y11P-2255ZJ10 connector series is designed to meet the performance requirements of relevant military (MIL-DTL-83723 Series III or similar) and industrial standards. Our processes ensure material compliance with RoHS and REACH. While standard units are built to these design specifications, project-specific certifications such as UL or CE can be supported, consistent with our capability demonstrated in certified Automotive Relay production.

Customization Options

YM offers significant customization to adapt the Y11P-2255ZJ10 connector to your exact application needs:

Contact Layout & Mix: Custom insert designs with specific arrangements of signal, power, coaxial, or filtered contacts.
Shell Modifications: Custom flange dimensions, mounting hole patterns, or shell lengths. Options for stainless steel shells in highly corrosive environments.
Special Sealing: Custom gasket materials (e.g., Viton for high-temperature/fuel resistance) to achieve specific IP ratings (IP68, IP69K).
Locking Mechanism: Variations in the locking system (different screw types, quick-disconnect levers) to match user requirements.
Integrated Components: Connectors can be supplied with contacts pre-loaded and wires terminated as a complete harness assembly.
Branding & Identification: Custom laser marking of part numbers, pin #1 indicators, or company logos on the shell.

Our proven OEM/ODM expertise, showcased in the development of custom Latching Relays and Flash Relays, enables us to collaborate closely with you to engineer a perfect connector solution.
