Aviation Connector
(Total 6 Products)
-
Brand:YMMin. Order:1Model No:Y11P-1419ZK10Military Aviation Connector Y11P-1419ZK10 | Micro-D Subminiature Sealed Connector System Product Overview The YM Military Aviation Connector Y11P-1419ZK10 is an ultra-compact, high-density Micro-D subminiature connector engineered for space-critical... -
Brand:YMMin. Order:1Model No:Y3AII-1832ZK10Military Aviation Connector Y3AII-1832ZK10 | High-Density D-Sub Connector for Harsh Environments Product Overview The YM Military Aviation Connector Y3AII-1832ZK10 is a ruggedized, high-density D-Sub connector engineered for reliable signal... -
Brand:YMMin. Order:1Model No:X158 24F19K1P40Military Aviation Connector and Socket X158 24F19K1P40 Advanced Interconnect Solution for Defense Applications Product Overview The Military Aviation Connector and Socket X158 24F19K1P40 represents a sophisticated, high-density interconnect solution... -
Brand:YMMin. Order:1Model No:X158 24T19K1P40+XC1Military Aviation Connector X158 24T19K1P40+XC1: Specialized High-Density Interconnect with Accessory Product Overview The Military Aviation Connector X158 24T19K1P40+XC1 is a specialized, high-density interconnect solution designed for complex... -
Brand:YMMin. Order:1Model No:JY27473T16B26PN + JY27472T16B26SNMilitary Aviation Connector JY27473T16B26PN with Socket JY27472T16B26SN Complete High-Reliability Interconnect System Product Overview The Military Aviation Connector JY27473T16B26PN and its compatible Military Aviation Socket JY27472T16B26SN form a... -
Brand:YMMin. Order:1Model No:Y11P-1007ZK10-ZMilitary Aviation Connector Y11P-1007ZK10-Z | Ultra-Compact Nano Circular Connector with Extended Features Product Overview The YM Military Aviation Connector Y11P-1007ZK10-Z represents the cutting edge of nano circular connector technology,...
ABC Specialized Aviation & Military Connectors: Engineered for Complex System Integration
ABC excels in providing advanced, mission-critical interconnection solutions for the aerospace and defense sectors. This product line showcases our specialized capabilities beyond standard connectors, featuring unique series like the compact Y11P-1210ZJ10, the robust XCE22T19K1P1, and integrated hybrid solutions such as the Aviation Switch XCE18T 11Z1P1 With Tail. Each of these Military Grade Connectors is engineered to solve specific challenges in signal integrity, environmental sealing, and space-constrained installations within avionics bays, cockpit panels, and weapon systems. As a leader in Aerospace Connectors, we deliver the precise, Durable Aviation Connectors that OEMs and MROs rely on for next-generation platforms and legacy system sustainment.
From the high-density KH33K12TPZ to the versatile YB2TAX+CXY-2ZX assembly, explore our portfolio of Reliable Aircraft Connectors designed for the most demanding integration challenges.
Technical Specifications & Model Profiles
Our specialized connectors are defined by their unique form factors, contact configurations, and integration-focused designs.
Featured Specialized Models
- Aviation Connector Y3B-2012ZK10-I: A compact, high-reliability connector series designed for specific instrumentation and sensor interfaces.
- Aviation Connector Y11P-1210ZJ10: Part of the versatile Y11P series, known for its rugged design in avionics and control system applications.
- Aviation Connector XCE22T19K1P1: A connector from the XCE series, potentially featuring a specific shell size (22) and contact layout (19 pins) for custom applications.
- Aviation Connector YB2TAX+CXY-2ZX: A complete assembly likely combining a connector plug with a specific backshell or conduit system for integrated wire management.
- Aviation Switch XCE18T 11Z1P1 With Tail: A hybrid component integrating a switching function (likely a micro switch) within a connector shell, providing a combined electrical interface and control point.
- Aviation Connector KH33K12TPZ: A high-density connector model, part of the KH series, designed for complex signal transmission with numerous contacts in a compact footprint.
Common High-Performance Attributes
- Diverse Shell Styles & Sizes: Ranging from miniature (e.g., Y11P, Y3B) to standard circular (XCE, JY27467) to specialized rectangular (KH) profiles to fit varied panel spaces.
- Precision Contact Configurations: Engineered for specific needs, from low-level signal (aviation connector 2 pin variants) to mixed power/signal (e.g., 8 pin military connector layouts) and high-density arrays (e.g., 12, 19, 35+ contacts).
- Hybrid & Integrated Functionality: Capability to combine connectors with switches, filters, or relays (as seen in the XCE18T model), reducing part count and increasing system reliability.
- Robust Environmental Performance: All models feature sealing to resist moisture, dust, and fluids. EMI/RFI shielding is standard or available for sensitive applications.
- Material & Construction: Shells of anodized aluminum or stainless steel; aviation grade terminals with gold plating; high-performance insulators.
Specialized Designs in Detail
Visual documentation highlighting the diversity, precision, and integration-ready nature of our specialized connector solutions.
Integrated Connector & Conduit Assembly (JY27467 Series)
High-Performance Military Connector (JY27467T17B266H)
Connector Socket with Integrated Tail (JY27473 Series)
J599 Series Standard Circular Connector
Mated J599 Pair with Protective Backshell
Compact Y11P Series Connector (Y11P-2255ZJ10)
Specialized Connector Assembly (YB2TAX+CXY-2ZX)
Features, Advantages & Integration Benefits
Our specialized connectors are designed to deliver performance and reliability where standard solutions fall short.
Core Product Features
- Space-Optimized Designs: Series like Y11P and Y3B offer high reliability in miniature form factors, crucial for modern, densely packed avionics racks and cockpit displays.
- Hybrid Function Integration: Components like the Aviation Switch XCE18T combine connectivity and switching, simplifying system architecture, reducing potential failure points, and saving valuable panel space.
- Superior Signal Integrity: Precise impedance control, advanced shielding, and high-quality aviation grade terminals ensure clean data transmission for sensitive avionics buses and sensor signals.
- Rapid Deployment & Maintenance: Many feature tool-less or quick-disconnect couplings, and integrated tail assemblies reduce on-site assembly time and error for MRO operations.
- Extreme Condition Resilience: Engineered to maintain performance through thermal cycling, intense vibration, and exposure to aviation fluids, adhering to strict military connector specifications.
The ABC Advantage for Complex Systems
- Application-Specific Expertise: We don't just sell catalog parts. We provide connectors designed for specific challenges, whether it's a 7 pin military connector for a navigation system or a custom hybrid for a weapons panel.
- Complete Sub-Assembly Supply: We provide value-added assemblies like the YB2TAX+CXY-2ZX, delivering a tested, ready-to-install module that reduces your labor and quality control burden.
- Legacy System Support: We maintain expertise and tooling for specialized and legacy series (e.g., XCE, KH, Y3B), ensuring long-term support for existing fleets.
Integration Guide for Specialized & Hybrid Connectors
Proper handling of specialized connectors, especially those with integrated functions, requires careful attention.
- Review Documentation & Identify Function: Carefully examine the datasheet or drawing for the specific model (e.g., Aviation Switch XCE18T). Identify which pins are for the switch function and which are for pass-through signals.
- Pre-Installation Testing (If Applicable): For hybrid units, manually actuate the integrated switch and check continuity with a multimeter to verify its normal state (NO/NC) before wiring.
- Precision Wire Termination: Terminate wires to the appropriate contacts. For high-density connectors like the KH33K12TPZ, use the correct insertion/removal tool. For models requiring aviation connector soldering, follow the specified thermal profile to avoid insulator damage.
- Contact Insertion & Verification: Insert each wired contact into its designated cavity in the connector insert. Use a pin-depth gauge if available. For complex layouts, reference a pinout diagram (akin to a 5 pin aviation connector wiring diagram).
- Assembly & Final Functional Check: Assemble any backshells or conduit. Before final mating, perform a continuity check on all circuits, including the switch function. Verify the switch actuates correctly and that the mating connector aligns properly.
Targeted Application Scenarios
These specialized connectors are deployed in systems where performance, space, and functionality are at a premium.
- Advanced Avionics Suites: Interconnecting modular mission computers, multifunction displays, and data concentrators in next-generation aircraft.
- Weapon & Targeting Systems: Providing reliable, high-density connections for electro-optical sensors, missile launchers, and fire control computers in military aircraft.
- Flight Control Actuation & Sensing: Connecting smart actuators, position sensors, and control units within fly-by-wire systems, where signal integrity is paramount.
- Ground & Test Equipment Interfaces: Used in specialized test rigs, simulator interfaces, and portable maintenance devices that require robust, multi-function connections.
- Unmanned Aerial Systems (UAS): Supplying compact, lightweight, and reliable connectors for datalinks, payloads, and control systems in drones.
Value for Design Engineers & Program Managers
Choosing ABC's specialized solutions delivers strategic advantages throughout the product lifecycle.
- Accelerate System Development: Off-the-shelf specialized and hybrid connectors can reduce custom design time, accelerate prototyping, and de-risk integration.
- Enhance System Reliability & Reduce Weight: Integrated designs (like connector-switch combos) reduce part count and interconnection points, improving overall reliability and potentially reducing weight—a critical factor in aerospace.
- Simplify Supply Chain & Logistics: Sourcing complex assemblies from a single qualified supplier like ABC simplifies procurement, reduces vendor management overhead, and ensures consistency.
- Ensure Long-Term Supportability: Our commitment to producing specialized and legacy parts guarantees a sustainable supply chain for the life of your platform, protecting your investment.
Certifications, Compliance & Engineering Partnership
Standards & Quality Assurance
Our specialized products are built on a foundation of rigorous standards and processes.
- Designed and tested to meet or exceed relevant performance requirements, including environmental specs from MIL-STD-810 and electrical specs from MIL-STD-461.
- Manufactured under an AS9100/ISO 9001 quality management system, with full material traceability and controlled processes.
- Compliance with army aviation quality control regulations and other customer-specific quality mandates is integral to our production.
Customization & Co-Development
Our core strength lies in adapting and creating solutions for unique applications.
- Electrical & Functional Customization: Custom pinouts, integration of specific switch types (micro switch, rocker switch), or incorporation of filtering elements within the connector shell.
- Mechanical & Form Factor Customization: Adaptation of shell dimensions, development of custom keying patterns, or creation of unique mounting interfaces to fit legacy or novel enclosures.
- Full Design & Prototyping Support: Collaborative engineering to develop completely new connector solutions or adapt existing ones to meet unprecedented system requirements.
