Military-Grade Aviation Connectors, Holders & Sockets
ABC Aviation is a premier manufacturer of military-grade aviation connectors and specialized aviation holders designed for the most demanding aerospace applications. Our comprehensive product portfolio includes J599 series connectors, CX-16 military connectors, and the complete Y11P series, engineered to deliver unmatched reliability in critical aircraft systems.
In aviation, every connection matters. Our aviation connectors with military grade quality are engineered to withstand extreme environmental conditions while maintaining perfect electrical integrity. Whether you're specifying components for military aircraft or commercial fleets, our products provide:
Y11P Series Connectors
Models: Y11P-1007ZK10-Z, Y11P-1419ZJ10, Y11P-2041ZK10, Y11P-2255ZJ10
Application: Avionics, instrumentation, control systems
Features: Environmental sealing, multi-pin configurations, rear release contacts
Compliance: Designed to military connector specifications
J599 Series Military Connectors
Models: 20WD35PN, 26FF11SN, various configurations
Application: High-density power & signal distribution
Features: Bayonet coupling, EMI shielding, power contacts
Environment: Extreme temperature & vibration rated
CX-16 Military Connector Series
Configurations: 3P, 5P, 7P, 10P variants
Application: Military aircraft systems, harsh environments
Features: Hermetic sealing, quick-disconnect, EMI protected
Special: True military aviation plug design
Y3A/Y3B Series Connectors
Models: Y3A-1832ZJ10, Y3A-1832ZK10, Y3B-2012ZK10-I
Application: General aviation, MRO, retrofit projects
Features: Cost-effective, reliable, easy installation
Options: Various pin counts including aviation connector 2 pin and 7 pin aviation connector configurations
Our aviation grade connectors and military aviation sockets are more than just components—they're critical elements in the safety and reliability chain of every aircraft system. From simple general aviation plugs to complex multi-contact assemblies, we deliver solutions that meet strict army aviation quality control regulations and commercial airworthiness standards.
Technical Specifications & Performance Data
Precision engineering defines every ABC Aviation connector. Below are detailed specifications for our core product lines. All data is based on standard operating conditions and validated through rigorous testing.
| Product Series | Contact Configuration | Electrical Ratings | Environmental | Mechanical | Materials & Finishes |
|---|---|---|---|---|---|
| J599 Series (20WD35PN, 26FF11SN) | 20-35 contacts Power/signal mix Rear release design | Voltage: 500V RMS Current: 7.5-23A/contact Power: 40A/contact | Temp: -65°C to +175°C Sealing: IP67 minimum Vibration: 15G, 10-2000Hz | Coupling: Bayonet Cycles: 500+ Insertion: 50N max | Shell: Aluminum alloy Plating: Cadmium/Ti-Cd Insulator: PTFE/DAP |
| CX-16 Military Series (3P, 5P, 7P, 10P) | 3, 5, 7, 10 pins Hermetically sealed EMI shielded | Voltage: 600V AC/DC Current: 13A continuous Intermittent: 20A | Temp: -65°C to +200°C Altitude: 70,000 ft Shock: 50G, 11ms | Coupling: Threaded Cycles: 1000+ Torque: 1.5-3.5 Nm | Shell: Stainless steel Seals: Silicone/FKM Contacts: Gold plated |
| Y11P Series (1007ZK10-Z, 2041ZK10) | 7-41 contacts Custom arrangements Front/rear removable | Voltage: 250V AC/DC Signal: 5A per contact Power: 20A per contact | Temp: -55°C to +125°C Humidity: 95% RH Fluid resistance: Skydrol | Coupling: Push-pull Cycles: 400+ Keying: Polarized | Shell: Anodized Al Contacts: Ag/CdO Insulator: PEEK |
| Y3A/Y3B Series (1832ZJ10, 2012ZK10-I) | 18-32 contacts Standard layouts Tool extraction | Voltage: 250V AC/DC Current: 10A continuous Peak: 15A | Temp: -55°C to +105°C Sealing: IP65 Vibration: 10G | Coupling: Bayonet Cycles: 300+ Mounting: Panel/flange | Shell: Nickel plated Contacts: Tin plated Gaskets: Neoprene |
For Aviation Application Purpose
With Military Grade Quality
